Hvala Vam na poverenju. Početna-8 x gigabit PoE+ ports and 2 x gigabit SFP slots
-120 watts total PoE power budget
-Extend mode(Port #7 ~ #8) supports PoE feeding up to 250 m
-IEEE 802.3af / 802.3at standard compliant
-IEEE 802.3X standard ?ow control
-Panel indicator monitoring status and help failure analysis
Power: AC100-240V50/60Hz
Ethernet: 8* Gigabit PoE Ports / 2* Gigabit SFP Ports
Chipset: 2*RTL8367S / RTL8238B
Bandwidth: 20Gbps
Pack forward rate: 14.88Mpps
MAC address: 2K
Jumbo Frame: 9216bytes
Transfer mode: Store and forward
MTBF: 100000 Hours
Network Protocol:
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-TX)
IEEE802.3x (Flow control)
PoE Protocol:
IEEE802.3af(15.4W)
IEEE802.3at(30W)
Industry Standard:
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD),
EN61000-4-4 (EFT),
EN61000-4-5 (Surge)
Network Medium:
10Base-T : Cat3, 4, 5 or above UTP(=100m)
100Base-TX : Cat5 or above UTP(=100m)
1000Base-TX : Cat5 or above UTP(=100m)
Optical Medium
Multimode optical fiber: 50/125, 62.5/125, 100/140um
Single-mode optical fiber: 8/125, 8.7/125, 9/125, 10/125um
LED Indicator: PWR (Power),1-10 Green Light (Link&Data)
PWR:
On: Powered on
Off: Powered off
1-10 Green Light (Link&Data)
On: Link normal
Off: Link blocked
Flashing: Data transmitting
DIP Switch
Default: common mode, all interfaces can communicate with each other, the transmission distance is less than 100 meters, the transmission rate is 10/100/1000M adaptive; The port AI mode is disabled
Extend: Link extension mode, 7-8 ports force 10M, link 250M (enable POE watchdog)
Structure Size
Product Dimensions: 220*161*44mm
Package Dimensions: 315*215*85mm
Product N.W: 0.88kg
Product G.W: 1.38kg
Packing Info
Carton Dimensions: 445*445*335mm
Packing Quantity: 10 PCS
Packing Weight: 14.8KG
Input Voltage: AC 100-240 V 50-60Hz
Supply Power: 52V2.3A
Power Consumption <30W
Working Environment:
Working Temperature: -10~50°C
Storage Temperature: -40~70°C
Working Humidity: 10%~90%, non-condensing
Storage Temperature: 5%~90%, non-condensing
